Pulsar APS 5 Battery Charger

Pulsar Merger XT50 Thermal Binoculars with Laser Rangefinder

Thermal performance with class.

The Pulsar Merger LRF represents Pulsar's classic thermal imaging binocular design with an integrated laser rangefinder.

These binoculars are remarkably ergonomic and comfortable. They allow for two-eye observation and reduce eye fatigue. They are equipped with top-tier components that exemplify European quality.

The Merger LRF XT50 is the first pair of thermal imaging binoculars from Pulsar to feature a remarkable 1280×1024, 12µm, <40mK NETD thermal sensor and built-in image stabilisation. These features lend another level of clarity and stability and provide greater observation opportunities without any distractions. Fully kitted out with a wide range of digital functionalities and connectivity options, including a built-in still image and video recorder, Stream Vision 2 compatibility, and a precision laser rangefinder, these binoculars are perfect for long-range, comfortable observation.

Features

European made thermal imaging sensors

Merger LRF Series ensures unrivalled thermal imaging experience. For image capture Merger binoculars use professional-grade, European made thermal imaging sensors:

• 12 micron sensors 1280×1024 and 1024×768 offer high definition image quality.
• 17 micron sensors 640×480 and 384×288 provide extreme thermal sensitivity.

Detailed and sharp image on high zoom

Optical magnification of the unit can be increased by means of digital zoom. Even at the highest level of zoom image detail is sufficient for identifying the smallest object details. Advanced algorithms enhance image quality and help to achieve sharp and detailed image.

Wide field of view

Wide field of view simplifies scanning and spotting hot objects while minimizing effects of image shaking and raising situational awareness. Excellent image detail on base magnification combined with wide field of view ensure improved viewing comfort and scene perception.

Extra-long detection range

Powerful germanium optics combined with professional thermal imaging sensors provide exceptional detection capabilities. Top Merger LRF units can detect hot objects at distances exceeding 2km.

User mode

Use the brightness and contrast adjustments to maximise the detail and informative value of the image in specific observation conditions. The User Mode function saves selected brightness and contrast settings in the device’s memory providing optimal image quality for the next use of the thermal imager immediately, with no additional adjustments needed.

Classic binocular design

Merger LRF thermal imaging binoculars are built with the classic design of daytime binoculars. With a small form factor, these thermal imaging binoculars fit comfortably in the hand, but still offer appealing external aesthetics and exemplary ergonomics. The six function buttons are placed in the comfort access zone and the most used digital device functions are activated with a single touch.

Comfortable viewing experience with both eyes

The Merger LRF binoculars’ optical design takes into account the nature of human vision. It is natural for a person to receive visual information through two visual channels simultaneously. Viewing with two eyes is less tiring than viewing with one. This means better detection of small or faint objects, and better performance in low-contrast scenarios than similar monocular thermal imaging devices with the same technical level. The interpupillary distance in the Merger LRF binoculars is adjustable from 63 to 74 mm in accordance with the individual characteristics of a particular user.

Precise laser rangefinder

Understanding the target distance is an essential factor in making the right decisions. A built-in laser rangefinder allows you to measure distances in single measurements and continuous scanning modes with an accuracy of ± 1 meters for quick and error-free assessment of the situation.

Combined dual battery system

The Merger LRF Series is powered with two rechargeable batteries: one built-in with a capacity of 4 Ah, the other replaceable with a capacity of 3.2 Ah. A single charge guarantees long battery life.

Other Features

• High-quality reinforced magnesium alloy housing
• Built-in photo and video recorder
• Stream Vision 2. Wi-Fi integration with iOS and Android devices
• Improved Wi-Fi connectivity with 2.4 / 5 GHZ waveband support
• High-contrast HD AMOLED displays
• IPX7 Waterproof Rated
• Wide range of operating temperatures (-25 to +50°C)
• A selection of 8 color palettes
• Proximity sensor
• Picture in Picture
• 3 Sensitivity enhancement levels
• Fast aperture F1.0 optics

Specifications

• Main
• Sensor: 1280x1024 @ 12 µm
• Objective lens: F50 / 1.0
• Magnification, x: 2 – 16
• FOV (HxV), degrees: 17.5 х 14
• FOV (HxV), m@100m: 30.7 х 24
• Detection range: 2300 m

Sensor

• Type: uncooled
• Resolution, pixels: 1280x1024
• Pixel pitch, µm: 12
• Sensor NETD, mK: < 40
• Frame rate, Hz: 50

Optics

• Objective lens: F50 / 1.0
• Magnification, x: 2 – 16
• FOV (HxV), m@100m: 30.7 х 24
• FOV (HxV), degrees: 17.5 х 14
• Interpupillary distance adjustment, mm: 62 – 74
• Eye relief, mm: 15

Display

• Type: AMOLED HD
• Resolution, pixels: 1280х960

Laser rangefinder

• Max. measuring range, m: 1500
• Measurement accuracy, m: ± 1
• Safety class for laser equipment according to IEC 60825-1:2014: 1
• Wavelength, nm: 905

Video recorder

• Video / photo resultion, pixel: 1280х960
• Video / photo format: .mp4 / .jpg
• Build-in memory, GB: 64

WI-FI

• Wireless protocol: Wi-Fi
• Wireless standard: IEEE 802.11 b/g/n/ac (WPA)
• Frequency, Ghz: 2.4 / 5

Environmental characteristics

• Degree of protection IP code (IEC60529): IPX7 (waterproof)
• Operating temperature range, °С: -25 – +50

Connections and compatibilities

• Mount type: 1/4" socket
• Supported application: Stream Vision 2

Power supply

• Output voltage, V: 3.7
• Battery type: Dual Li-Ion B-Pack Mini Power System: 2 A·h Changeable Battery (external) / 4.9 A·h Battery (internal)
• Capacity, mAh: 3200 (external) + 4000 (internal)
• Operating time on battery pack, h at t=22°С: 8
• External power supply, V: 5V; 9V (USB Type-C Power Delivery)

Weight & size

• Body material: Magnesium alloy
• Dimensions, mm: 197x140x72
• Weight, kg: 0.95 (batteries included)
• SKU: 77486

ThermTec Ares 660L 2.0

ARES 660L 2.0 is designed for hunters who pursue precision shooting and hunting in different environments. It features an integrated 1000m laser rangefinder and ballistic calculation, significantly enhancing long-range shooting accuracy. With a powerful 640x512 resolution and NETD =20mK sensor, along with a dual field of view lens (20mm/60mm), it offers 3x optical zoom and 4x digital zoom, enabling the detection and observation of details across various distances. Incorporating the latest technology and optimizing user experience, ARES660L 2.0 is the ideal compact thermal imaging scope for precise and efficient hunting.

Features:

More Features

• 0.39-inch AMOLED Display
• IP67 Waterproof Rated
• Picture-in-Picture Function
• 5 Color Palettes
• 5 Zeroing Profiles
• -20C ~ +50C Operating Temperature
• 64GB Inbuilt Memory
• 2600m Detection Range

Specifications

Guide TB1250 Pro Thermal Clip-On with Laser Rangefinder

Introducing the Guide Sensmart Compact Clip-On TB 1250 LRF Pro —the first thermal clip-on on the market with a HD 1280x1024 resolution. This groundbreaking technology brings exceptional thermal image quality to night hunters, making high-definition thermal imaging a reality.

Key Features

• 1280×1024 @12μm Sensor Resolution
• 2800 yd Detection Range
• 50mm; F1.0 Focal length
• 1920x1080 Full HD Display
• 1630Yd Laser Rangefinder

The TB Series of thermal clip-ons were specifically designed to be compact and lightweight, but they come with all the features that you can expect, which include: built-in recording and picture capture capabilities, laser rangefinder with ultra long distance of up to 1000m, full HD AMOLED display bringing a rich and detailed visual experience, Wi-Fi hotspot, intelligent functions such as image tracing and automatic recording after each shot, TargetIR app compatibility for storing and sharing images and videos, constant OTA upgrades, IP67 protection rating, 6 hours of battery life and more.

Features

Mega-Pixel infrared detector, NETD reaches 18mK

TB LRF Pro Series adapts the high-sensitive 12μm detector of 1280×1024 infrared resolution with NETD down to 18mK. The advanced detector can distinguish the slightest differences and changes in temperature.

Ultra-long laser ranging, 1000m built-in LRF

The built-in LRF module provides a long laser rangefinder of up to 1000m/1090yd, enabling users to detect and locate the targets quickly and precisely.

50mm lens for more image details

TB LRF Pro Series utilizes a longer focal length of 50mm to provide a longer observation distance and more image details than the common lens.

Stunning visual experience, Full-HD AMOLED display

TB LRF Pro Series has a 0.39'' AMOLED 1920x1080 display screen, presenting a vivid image with more details for users.

Target detection range up to 2600m

A maximum detection range of 2600m/2800yd, can detect targets in a long distance, which will help you see farther and observe more outdoors.

IP68 waterproof, durable quality

Compact and rugged, portable and powerful, the TB LRF Pro Series sports the high protective features of IP68, to support your outdoor adventures in the harsh environment.

Specifications

Sensor

• Type: Uncooled VOx Infrared Detector, 8 to 14μm
• Resolution: 1280×1024@12μm
• NETD: 18mK
• Frame rate: 50Hz

Lens

• Objective: lens 50mm, F1.0
• Field of view: 17.5°×14.0°
• FOV m@100m: 31×25
• Magnification: 1x
• Detection range: 2600m/2800yd

Display

• Display type: 0.39'' AMOLED 1920×1080
• Colour palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece Eye relief: 20mm; Zoom: 13.3x

Hardware

• Laser rangefinder: 1500m/1630yd
• WIFI: 2.4G, 5G
• Interface: USB Type-C (Power supply/USB2.0)
• Others: Microphone, Bluetooth

System

• Recording function: Photo/Video (Audio recording included)
• Memory capacity: 256GB

Power

• Battery type: 2 replaceable 18650 batteries
• Operating time: 6 hours

Environmental

• Operating temp.: -20°C to 50°C
• Shock: 1000G at 1ms half sine pulse (as per IEC60068-2-27)
• Encapsulation: IP68

Physical

• Weight (g/oz): 617/21.76
• Size (cm/in): 161×89×97/6.34×3.50×3.82
• Standard: A device, Battery charger, 18650 battery×2, 5V2A adapter (US, Britain, Australia and Europe), USB Type-C cable, Quick use guide, Warranty card
• Optional: 18650 battery, Bluetooth remote control, Cover ring adapter

The first thermal imaging riflescope with classic design and built-in laser rangefinder

The laser rangefinder is seamlessly integrated into a slim design riflescope. The rangefinder is compact, the receiver and emitter are within clearance limits of a single optical channel. The measuring range is 800 metres – the Thermion 2 LRF provides the hunter with an accurate sense of distance at the hunting site helping to take a precise shot.

Features:
• Variable magnification
• High-precision aiming in the "Picture-in-picture" mode
• 5 individual shooting profiles / 50 zeroing distances
• A selection of 10 reticle shapes in 9 color modes
• Mounting on standard 30 mm rings
• Instant Start-up
• High caliber recoil resistance: 12 gauge, 9.3x64, .375H&H
• Completely waterproof IPX7
• Operating temperature range: -25 to +50 °C
• High contrast HD AMOLED display
• A selection of 8 color palettes
• Wide-angle eyepiece for comfortable observation
• Photo and video recording
• Stream Vision 2. WiFi integration with iOS and Android devices

Specifications:
• Sensor: 384x288 @ 17 µm (NETD <25 mK)
• Objective lens: F50 F/1.0
• Magnification: 3-12x
• Detection range: 1800 m
• Field of view (HxV), degrees / m@100m: 7.5 / 13.1
• Eye relief: 50 mm
• Type: Uncooled
• Resolution: 384x288 Pixels
• Pixel pitch: 17 µm
• NETD: <25 mK
• Frame rate: 50 Hz
• Type: AMOLED
• Resolution: 1024х768 Pixels
• Click value H/V(mm at 100 m): 13 – 3х 6.5 – 6х 3.25 – 12
• Click range H/V(mm at 100 m): 2600 / 2600
• Number of preloaded reticles: 10+
• Video / photo resolution: 1024x768 Pixels
• Video / photo format: .mp4 / .jpg
• Built-in memory: 16 GB
• Wireless Protocol: Wi-Fi
• Wireless Standard: IEEE 802.11 b/g/n/ac (WPA)
• Frequency: 2.4 / 5 GHz
• Degree of protection, IP code (IEC60529): IPX7
• Operating temperature range: -25 – +50 °С
• Max. recoil power on rifled weapon: 6000 Joules
• Compatible mounts: Standard 30 mm Rings
• Supported Application: Stream Vision 2
• Output voltage: 3.7 V
• Battery type: Li-ion APS2
• Capacity: 4900 mAh
• Operating time on battery pack(at t=22°C): 10 hours
• External power supply: 5 V /9 V (USB Type-C Power Delivery)
• Body material: Aluminum
• Dimensions: 420 x 78.5 x 94.5 mm
• Weight: 0.97 Kg

Laser Rangefinder
• Wavelength: 905 nm
• Max. measuring range: 800 m
• Measurement accuracy: ± 1

Warranty period on new thermal optics:
• Pulsar: 3 Year manufacturers warranty
• Guide: 1 Year + Register online and get an extra year: https://www.guideir.com/service/free-extended-warranty
• InfiRay: 2 Year warranty: https://www.infiray.com/uploads/file/after-sales-service-policy.pdf

Please note: Manufacturers warranty period above covers the unit itself and does not cover commercial use. Thermal accessories will have a lesser cover period that what is specified for the units above. The warranty does not cover mis-use or accidental damage caused by the operator.

Guide TU650 640x512 50mm Thermal Scope Laser Rangefinder

The TU 3.0 Series redefines precision optics with advanced thermal imaging, modular design, and AI powered performance. Offered in six sub-series—from ultra-light compact units to dual-spectrum, longrange solutions—they meet the demands of hunters, professionals, and tactical users alike. Featuring AI enhanced imaging, shutterless design, ergonomic controls, IP68 protection, and dual-band Wi-Fi, they deliver reliable performance in any environment.

Hyper-Light Algorithm Ultra-Premium Visuals

Powered by next-gen sensors and the Hyper-light algorithm, the product boosts image quality on multiple levels through improved clarity, reduced noise, optimized contrast, and enhanced resolution of fine details.

Lightweight Design Compact Housing

Compared to the previous generation, TU LRF 3.0 adopts a more compact and lightweight design, making it over 200g lighter than its predecessor with the same configuration. Its slim, metallic housing provides a comfortable grip.

Shutterless Design Uninterrupted Visuals

The innovative shutterless 3.0 technology eliminates the clicking sound and image freezing, ensuring uninterrupted real-time footage during actual hunts, in case any shots are lost or missed during calibration.

Locate with Accuracy Up to 1500m

The TU LRF 3.0 Series integrates a precise laser rangefinder that can easily locate prey up to 1,500 meters, assisting hunters in achieving a successful hunt in the field.

Seamless Control Easy Focus & Zoom

Built on extensive field testing and hunter feedback, TU LRF 3.0 was refined in every detail—from the focus wheel to the zoom lever and button layout. The ergonomic design is crafted for comfort and intuitive control.

Specifications for Guide TU650 640x512 50mm Thermal Scope Laser Rangefinder:

Sensor:

• Type: Uncooled VOx Infrared Detector, 8 to 14µm
• Resolution: 640×512@12µm
• NETD: 18mK
• Frame rate: 50 Hz

Lens:

• Objective lens: 50mm, F1.0
• Field of view: 8.2°×5.0°
• FOV m@100m: 14×9
• Magnification: 3.9x~31.2x
• Detection range: 2600m/2800yd
• Focus: Manual

Display:

• Display type: 0.49'' AMOLED 1920×1080
• Color palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece: Eye relief: 48mm; Diopter -5 to +5; Zoom: 14x

Hardware:

• Laser rangefinder: 1500m/1630yd
• WIFI: 2.4G, 5G
• Interface: USB-C (Charge/USB2.0)
• Tube diameter: Standard 30 mm
• Others: Microphone, Bluetooth

System:

• Recording function: Photo/Video (Audio recording included)
• Memory capacity: 128GB

Power:

• Battery type: 18500 ×1 Battery (Built-in) and 18650 ×1 Battery (External)
• Operating time: 12 hours

Environmental:

• Operating temp.: -20°C to 50°C / -4°F to +122°F
• Shock: 6000J/1200G
• Encapsulation: IP68

Physical:

• Weight (g/oz): 815/28.75
• Size (mm/in): 377×89×82/14.84×3.50×3.23
• Standard: Device, Lens Cover, Eye Mask, Quick-Release Scope Mount, Carry Bag, 18650 Battery ×2, Battery Charger, 5V 2A Adapter (US or UK or Australia or Europe), USB-A to USB-C Cable, Quick Start Guide, Warranty Card

The TU Gen2 Series is equipped with a high-sensitivity thermal sensor of 12μm and a 1440×1080 HD AMOLED display. Paired with the robust PureIR image algorithm, it provides users with a more vivid and detailed visual experience. With the laser rangefinder seamlessly integrated into a slim-design scope, the TU Gen2 LRF Series enables precise detection of targets at distances of up to 1,500 meters, empowering hunters with a reliable perception of distance at the hunting site to make accurate shots. The Guide TU Series has undergone meticulous optimization in its detailed design, elevating user-friendly operation. Furthermore, the battery life has seen a substantial extension, resulting in a 20% increase in duration.

High Definition Thermal Sensor

High-quality thermal imaging with 640×480@12μm resolution with clear distinctions allows for improved recognition of animals, their body parts, and even minute elements such as branches, leaves, grass, and the landscape.

1440×1080 AMOLED Display

The heat signature captured by the thermal image can be shown on the display using the picture-in-picture (PIP) feature, significantly enhancing the comfort of observation.

PureIR Adaptive Dynamic Filtering Algorithm (PureIR)

The PureIR combining 3DNR and PureIR adaptive filtering algorithms delivers high-sensitivity thermal images, reducing image distortion and enriching detail even for distant targets.

Fast Detection 1500m LRF

The compact ranging module, which has been recently created, offers accurate and rapid detection, allowing you to identify targets at distances of up to 1500 meters during nighttime hunting, thus enhancing your hunting efficiency.

Infrared detector

• Detector type: Uncooled VOx Infrared
• Detector resolution and pitch: 640 × 480, 12 μm
• Spectral range: 8 to 14 μm
• NETD: ≤30 mk
• Frame rate: 50 Hz

Lens

• Focal length: 50 mm; F1.0
• Focus: Manual
• Field of View: 8.8° × 6.6°
• Optical zoom: 2.36x
• Digital zoom: 1x ~ 8x

Display

• Display type: 0.39" AMOLED
• Resolution: 1440 x 1080
• Eyepiece: Exit pupil distance≥ 48mm; Diopter: +/- 4 to; Zoom: 14x
• Video output: Digital video

Power

• Battery type: Single Replaceable external battery (Guide specific part)
• Battery life: ≥ 12 hours

Interface

• USB: Type C
• Video Interface: Micro HDMI
• Tube Diameter: 30mm

Range Performance

• Detection range: 2000 m

Laser rangefinder

• Max. measuring range: 1500m

Functions

• Scene modes: Enhanced, Highlight and Natural
• Color palettes: Black Hot, White Hot, Red Hot, Iron Hot, Blue Hot
• PIP: Available
• Hot spot tracking: Available
• WIFI: 2.4 G
• Supported Application: TargetIR
• Firmware OTA: Upgrade device firmware via app connection

Environmental

• Operating temperature range: -30°C to 50°C
• Storage temperature range: -40°C to 70°C
• Humidity: 10 % to 95 % non-condensing
• Shock: 800 G at 1 ms half-sine pulse
• Encapsulation: IP67
• Certification: FCC, CE, RoHS, EAC, un38.3

Physical:

• Weight: ≤ 1250 g
• Dimensions: 377 × 107 × 99 mm

Included in box...

• Device
• Lens cap
• Eye masks
• 5V2A adapter (US, Britain, Australia and Europe)
• Desktop charger
• Customized battery ×2
• Extended clip ×2
• USB Type-C cable
• Micro HDMI cable
• Quick start guide

Introducing the Pulsar Talion XQ35 Pro Thermal Rifle Hunting Scope. Replacing the previous Talion XQ38 model, the new XQ35 Pro offers an improved image quality, <25mk NETD rating for more detailed imaging and a wider field of view. The Pulsar Talion XQ35 Pro takes an already great scope and makes it even better!

The Pulsar Talion XQ35 Pro's 384x288 thermal resolution enables you to detect targets with utmost clarity, even in challenging environments and poor conditions. With a remarkable sub <25mk NETD rating sensor, you'll experience enhanced sensitivity, providing a significant advantage when spotting animals at a wide range of distances

Equipped with a 2.5x base magnification and wide FOV, the Talion XQ35 Pro lets you observe targets up close but the powerful 10x digital zoom allows you to hone in on your target at longer ranges ensuring you never miss a shot. Whether it's a distant coyote or an up close hog lurking in the brush, the XQ35 Pro provides a positive ID range at up to 250 yards, giving you the confidence to make accurate decisions in the heat of the hunt.

Not only does the Pulsar Talion XQ35 Pro deliver excellent performance, but it also includes a huge list of great features such as; internal audio and video recording, WiFi streaming with the Pulsar Stream Vision 2 app, picture in picture function, multiple reticles options and a wide variety of color pallets. With a recoil rating up to a 12 gauge shotgun or a .375 H&H and multiple rifle zeroing profiles, you can easily swap the Talion between different rifles. The Talion also features a fully removable and rechargeable Pulsar APS5-T battery pack that will allow you to stay in the field for hours on end.

If you're looking for an affordable thermal scope that still offers great image quality and all the features you want and need for your time in the field, look no further than the Pulsar Talion XQ35 Pro.

Features

• Long operation time on a single charge

Talion is powered with a Pulsar APS 5T interchangeable, rechargeable battery. A single charge guarantees up to 9 hours of battery life (Talion XQ series), which covers the time of active use of the scope for a hunt. The battery cover design helps to accurately determine the correct position and makes it possible to quickly replace a flat battery with a new one in complete darkness by touch alone.

• Multi-point prism mount for precise positioning on a rifle

A mounting prism with multiple screw points to ensure flexibility and convenience when installing a Talion riflescope on various types of rifles. During installation the user can shift the scope along the rifle to the most comfortable viewing position.

• All control elements in direct access

All Talion riflescope controls are placed on the top panel of the eyepiece to simplify access and for the convenience of both right- and left-handed users.

• Rapid battery extraction mechanism

Unique battery cover design with rapid extraction lock ensures fast and flawless battery replacement. Releasing the lock opens and raises the battery cover at the top of the riflescope’s housing for quick access to rechargeable battery.

• Focus adjustment with tactile marker set for night-time shot

The precise focusing adjustment has an integrated fin lever that is set to match the protruding ridge on the housing of Talion riflescope when focusing reaches 70 m (76 yd) mark, the night-time shooting distance. This enables quick and correct focusing, even without looking at the riflescope.

More sensitive than ever

• User mode

Use the brightness and contrast adjustments to maximise the detail and informative value of the image in specific observation conditions. The User Mode function saves selected brightness and contrast settings in the device's memory providing optimal image quality for the next use of the thermal imager immediately, with no additional adjustments needed.

• 3 sensitivity amplification levels

Selection of the signal amplification level combined with new filtration algorithms with fine brightness and contrast adjustments offers the hunter great opportunities for long-range detection of game under diverse weather and temperature conditions. The amplification setting helps to define an animal’s trophy features and ensures clear rendering of objects and background in the field of view.

• Lightweight and rugged magnesium alloy housing

The Talion’s housing is made of magnesium alloy to ensure great structural strength and retain a light weight. The robust and lightweight metal housing serves also as a heat sink extracting the warmth generated by inner electronics thus making thermal imaging device more sensitive.

• Photo and video recording

Keep the best moments of observation and share them with your friends and hunting colleagues. One touch of a button is enough to capture an interesting moment or start recording video. 16 GB of internal memory enables recording many hours of video and tens of thousands of photos.

• Wi-Fi integration with iOS and Android devices. Stream Vision 2 application

The built-in Wi-Fi module will connect the device with smartphones based on Android and iOS via the Stream Vision 2 mobile application. This combination provides a great opportunity, such as wireless updating of the device software, transmission of images to a mobile device screen in real time, remote control of digital functions and many others. Users registered in the application are provided with cloud storage space for photos and videos taken with a digital or thermal imaging device.

• Waterproof IPX7 housing

With an IPX7 waterproof rating, Talion riflescopes work in conditions of high humidity and heavy rain and can withstand half an hour immersion under water to a depth of 1 meter.

High calibre recoil resistance: 12 gauge, 9.3x64, .375H&H

Talion thermal riflescopes are high impact resistant and can be used with rifled hunting weapons with calibres of 9.3x64, .30-06, .300, .375H&H, etc., as well as with smooth-bore and pneumatic weapons.

• 5 shooting profiles / 50 zeroing distances

Zeroing settings are saved in a shooting profile. Talion memory contains up to five shooting profiles for several types of weapons or cartridges. Each profile can hold up to ten zeroing distances.

• A selection of 10 reticle shapes in 9 colour modes

A reticle is electronically displayed in the same plane as the target. The Talion memory contains ten reticle configurations and functions (direct shot type, ballistic, scalable and regular), all available in nine colour options.

• Precision aiming in the “Picture-in-picture” mode

The “Picture-in-picture” function enables the shooter to display a high-precision zeroing frame. Taking only 10% of the total display area, the frame shows a magnified image of the target and reticle and allows the user to closely see the image in the aiming area and have visual control of the entire field of view at the same time.

• Variable colour palettes

A choice of 8 colour palettes lets the user observe their field of view more effectively, allowing them to optimise the unit for specific tasks and react to changing observation conditions. White Hot, Black Hot and Red Hot are optimal for object detection, and Rainbow and Ultramarine help increase chances for recognition & identification. Red Monochrome, Sepia and Violet are best suited to long-range observation at night.

Mounts
Talion riflescopes come in 4 versions:

• Without the mount
• Equipped with the Weaver U Mount
• Equipped with the Weaver USQD Mount
• Equipped with the Weaver LQD Mount

Specifications:

Main

• Sensor: 384x288 @ 12 µm (NETD <25 mK)
• Objective lens: F35 / 1.0
• Magnification: 2.5 – 10x (x8 zoom)
• Field of view (HxV): 10.7х8 / 18.2x13.7
• Detection range: 1350m

Sensor

• Type: uncooled
• Resolution: 384x288 pixels
• Pixel pitch: 17µm
• NETD: < 25mK
• Frame rate: 50Hz

Optics

• Objective lens: F35 / 1.0
• Magnification: 2.5 – 10
• Field of view (HxV), degrees / m @ 100 m: 10.7х8 / 18.2x13.7
• Eye relief: 50mm

Display

• Type: AMOLED
• Resolution, pixels 1024х768

Reticle

• Click value, H/V, mm at 100 m: 18 / 18 (on minimum magnification)
• Click range, H/V, mm at 100 m: 3600 / 3600
• Number of preloaded reticles: 10

Video Recorder

• Video / photo resolution: 1024x768 pixels
• Video / photo format: .mp4 / .jpg
• Built-in memory: 16GB

Wi-Fi

• Wireless Protocol: Wi-Fi
• Wireless Standard: IEEE 802.11 b/g/n/ac (WPA)
• Frequency: 2.4 / 5 GHz

Environmental Characteristics

• Degree of protection: IPX7 IP code (IEC60529)
• Operating temperature range: -25 – +50 °С

Connections and Compatibilities

• Max. recoil power on rifled weapon (Eo): 6000Joules
• Shock resistance on the smooth-bore rifles, caliber: 12
• Compatible mounts: Weaver U Mount, Weaver USQD Mount, Weaver LQD Mount
• Supported Application: Stream Vision 2

Power Supply

• Output voltage: 3.0 – 4.2V
• Battery type: APS 5T
• Capacity: 4900 mAh
• Operating time on battery pack (at t=22°C), h *: 9
• External power supply: 5 V, 9 V (USB Type-C Power Delivery)

Weight & Size

• Body material: Magnesium alloy
• Dimensions: 330x57x67mm
• Weight: 0.7kg (without APS 5T battery)

Trade Data

• SKU (Model #): 76566

Key Features

• NETD <20mK Detector
• 640×512@12µm Resolution
• Full HD 0.5'' AMOLED 1600×1200 Display type
• 2600m/2800yd Detection range
• up to 1500m Laser range
• IP67 Encapsulation

The Guide TJ LRF Pro Series is equipped with a 12µm high-sensitivity infrared detector, providing clear and realistic visibility of targets in low-light conditions. Its 0.5” large AMOLED display delivers a visual experience comparable to a home theatre. Furthermore, the integrated 1500m laser rangefinder, which can be activated with a single button, enhances the safety and ease of your explorations.

The TJ LRF Pro Series features an advanced 12µm infrared detector with a NETD of 20mK, enabling it to detect minute temperature differences even in total darkness. Its large 1600 x 1200 AMOLED display offers an exceptional visual experience, similar to watching a 90” home theatre screen from 2.5 metres away, enhancing both image clarity and viewing comfort.

The TJ LRF Pro Series provides flexibility with its various focal lengths, making it perfect for long-range observation and hunting. The 50mm F1.0 lens can identify targets up to 2600 metres away, while the 35mm F1.0 lens has a detection range of 1800 metres.

Utilising standard 18650 batteries with an integrated safety circuit protection design, you simply need to ensure the positive and negative poles of the two cells are positioned oppositely during replacement. This makes the process easier and minimizes the need for identification and memorisation.

The device is user-friendly for both left and right-handed operation, with easily interchangeable eye masks and hand straps. It also features photo and video capture capabilities, complete with a built-in microphone for audio recording.

Features

• 12µm advanced thermal detector, NETD down to 20mK
• Stunning visual effects like a 90” home theatre at 2.5m distance
• Laser Range Finder up to 1500m
• Video recording including sound
• 0.5" AMOLED display, top-notch visual effect
• 50mm F1.0 lens
• 1800m/2600m detection range
• Unique design for easy operation in the dark
• Ambidextrous design
• Video recording including sound

Specifications

Sensor

• Type Uncooled VOx Infrared Detector, 8 to 14µm
• Resolution 640×512@12µm
• NETD 20mK
• Frame rate 50Hz

Lens

• Objective lens 50mm, F1.0
• Field of view 8.8°×6.6°
• FOV m@100m 15x12
• Magnification 4.73x~37.84x
• Detection range 2600m/2800yd

Display

• Display type 0.5'' AMOLED 1600 x 1200
• Color palettes White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece Exit pupil distance 16 mm; Diopter: -6 to +6; Zoom: 18x

Hardware

• Laser rangefinder 1500m/1630yd
• WIFI 2.4G, 5G
• Interface USB Type-C (Power supply/USB2.0)
• Others Microphone, Compass, Gyroscope, Bluetooth

System

• Recording function Photo/Video (Audio recording included)
• Memory capacity 64GB

Power

• Battery type 2 replaceable 18650 batteries
• Operating time 9 hours

Environmental

• Operating temp. -30°C to 55°C / -22°F to +131°F
• Encapsulation IP67

Physical

• Weight (g/oz) 618/21.80
• Size (mm/in) 247 x 101 x 70/9.72 x 3.98 x 2.76
• Optional Bluetooth remote control, 18650 battery

Included

• Guide TJ LRF Pro Handheld Thermal Imaging Monocular
• Wrist strap
• Battery charger
• 18650 battery x 2, 5V2A adapter (US, Britain, Australia and Europe)
• USB Type-C cable
• Quick use guide
• Guide warranty card

Guide TU435L 3.0 400x300 35mm Thermal Scope Laser Rangefinder

The TU 3.0 Series redefines precision optics with advanced thermal imaging, modular design, and AI powered performance. Offered in six sub-series—from ultra-light compact units to dual-spectrum, longrange solutions—they meet the demands of hunters, professionals, and tactical users alike. Featuring AI enhanced imaging, shutterless design, ergonomic controls, IP68 protection, and dual-band Wi-Fi, they deliver reliable performance in any environment.

Hyper-Light Algorithm Ultra-Premium Visuals

Powered by next-gen sensors and the Hyper-light algorithm, the product boosts image quality on multiple levels through improved clarity, reduced noise, optimized contrast, and enhanced resolution of fine details.

Lightweight Design Compact Housing

Compared to the previous generation, TU LRF 3.0 adopts a more compact and lightweight design, making it over 200g lighter than its predecessor with the same configuration. Its slim, metallic housing provides a comfortable grip.

Shutterless Design Uninterrupted Visuals

The innovative shutterless 3.0 technology eliminates the clicking sound and image freezing, ensuring uninterrupted real-time footage during actual hunts, in case any shots are lost or missed during calibration.

Locate with Accuracy Up to 1500m

The TU LRF 3.0 Series integrates a precise laser rangefinder that can easily locate prey up to 1,500 meters, assisting hunters in achieving a successful hunt in the field.

Seamless Control Easy Focus & Zoom

Built on extensive field testing and hunter feedback, TU LRF 3.0 was refined in every detail—from the focus wheel to the zoom lever and button layout. The ergonomic design is crafted for comfort and intuitive control.

Specifications for Guide TU435L 3.0 400x300 35mm Thermal Scope Laser Rangefinder:

Sensor:

• Type: Uncooled VOx Infrared Detector, 8 to 14µm
• Resolution: 400×300@12µm
• NETD: 20mK
• Frame rate: 50 Hz

Lens:

• Objective lens: 35mm, F1.0
• Field of view: 7.4°×4.4°
• FOV m@100m: 13×8
• Magnification: 4.4x~17.6x
• Detection range: 1800m/1950yd
• Focus: Manual

Display:

• Display type: 0.49'' AMOLED 1920×1080
• Color palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece: Eye relief: 48mm; Diopter -5 to +5; Zoom: 14x

Hardware:

• Laser rangefinder: 1500m/1630yd
• WIFI: 2.4G, 5G
• Interface: USB-C (Charge/USB2.0)
• Tube diameter: Standard 30 mm
• Others: Microphone, Bluetooth

System:

• Recording function: Photo/Video (Audio recording included)
• Memory capacity: 128GB

Power:

• Battery type: 18500 ×1 Battery (Built-in) and 18650 ×1 Battery (External)
• Operating time: 12 hours

Environmental:

• Operating temp.: -20°C to 50°C / -4°F to +122°F
• Shock: 6000J/1200G
• Encapsulation: IP68

Physical:

• Weight (g/oz): 780/27.51
• Size (mm/in): 374×89×82/14.72×3.50×3.23
• Standard: Device, Lens Cover, Eye Mask, Quick-Release Scope Mount, Carry Bag, 18650 Battery ×2, Battery Charger, 5V 2A Adapter (US or UK or Australia or Europe), USB-A to USB-C Cable, Quick Start Guide, Warranty Card

The TU Gen2 Series is equipped with a high-sensitivity thermal sensor of 12μm and a 1440×1080 HD AMOLED display. Paired with the robust PureIR image algorithm, it provides users with a more vivid and detailed visual experience. The TU Gen2 Series has undergone meticulous optimization in its detailed design, elevating user-friendly operation. Furthermore, the battery life has seen a substantial extension, resulting in a 20% increase in duration.

High Definition Thermal Sensor

High-quality thermal imaging with 400×300@12μm resolution with clear distinctions allows for improved recognition of animals, their body parts, and even minute elements such as branches, leaves, grass, and the landscape.

1440×1080 AMOLED Display

The heat signature captured by the thermal image can be shown on the display using the picture-in-picture (PIP) feature, significantly enhancing the comfort of observation.

PureIR Adaptive Dynamic Filtering Algorithm (PureIR)

The PureIR combining 3DNR and PureIR adaptive filtering algorithms delivers high-sensitivity thermal images, reducing image distortion and enriching detail even for distant targets.

Infrared detector

• Detector type: Uncooled VOx Infrared
• Detector resolution and pitch: 400 × 300, 12 μm
• Spectral range: 8 to 14 μm
• NETD: ≤30 mk
• Frame rate: 50 Hz

Lens

• Focal length: 35 mm; F1.0
• Focus: Manual
• Field of View: 7.8° × 5.9°
• Optical zoom: 2.65x
• Digital zoom: 1x ~ 4x

Display

• Display type: 0.39" AMOLED
• Resolution: 1440 x 1080
• Eyepiece: Exit pupil distance≥ 48mm; Diopter: +/- 4 to; Zoom: 14x
• Video output: Digital video

Power

• Battery type: Single Replaceable 18650 battery
• Battery life: ≥ 12 hours

Interface

• USB: Type C
• Video Interface: Micro HDMI
• Tube Diameter: 30mm
• Memory Capacity: 128 gb
• Language Settings: English / Russian / German / French / Italian / Spanish / Japanese / Korean / Polish

Range Performance

• Detection range: 1000 m

Functions

• Scene modes: Enhanced, Highlight and Natural
• Color palettes: Black Hot, White Hot, Red Hot, Iron Hot, Blue Hot
• PIP: Available
• Hot spot tracking: Available
• WIFI: 2.4 G
• Supported Application: TargetIR
• Firmware OTA: Upgrade device firmware via app connection

Environmental

• Operating temperature range: -30°C to 50°C
• Storage temperature range: -40°C to 70°C
• Humidity: 10 % to 95 % non-condensing
• Shock: 800 G at 1 ms half-sine pulse
• Encapsulation: IP67
• Certification: FCC, CE, RoHS, EAC, un38.3

Physical:

• Weight: ≤ 990 g
• Dimensions: 377 × 107 × 99 mm

Included in box...

• Device
• Lens cap
• Eye masks
• 5V2A adapter (US, Britain, Australia and Europe)
• Desktop charger
• Customized battery ×2
• Extended clip ×2
• USB Type-C cable
• Micro HDMI cable
• Quick start guide

Guide TU435 3.0 400x300 35mm Thermal Scope

The TU 3.0 Series redefines precision optics with advanced thermal imaging, modular design, and AI powered performance. Offered in six sub-series—from ultra-light compact units to dual-spectrum, longrange solutions—they meet the demands of hunters, professionals, and tactical users alike. Featuring AI enhanced imaging, shutterless design, ergonomic controls, IP68 protection, and dual-band Wi-Fi, they deliver reliable performance in any environment.

Hyper-Light Algorithm Ultra-Premium Visuals

Powered by next-gen sensors and the Hyper-light algorithm, the product boosts image quality on multiple levels through improved clarity, reduced noise, optimized contrast, and enhanced resolution of fine details.

Lightweight Design Compact Housing

Compared to the previous generation, TU 3.0 adopts a more compact and lightweight design, making it over 200g lighter than its predecessor with the same configuration. Its slim, metallic housing provides a comfortable grip.

Shutterless Design Uninterrupted Visuals

The innovative shutterless 3.0 technology eliminates the clicking sound and image freezing, ensuring uninterrupted real-time footage during actual hunts, in case any shots are lost or missed during calibration.

Seamless Control Easy Focus & Zoom

Built on extensive field testing and hunter feedback, TU 3.0 was refined in every detail—from the focus wheel to the zoom lever and button layout. The ergonomic design is crafted for comfort and intuitive control.

Rugged Design All-Weather Reliability

Engineered for all-weather reliability, TU 3.0 performs flawlessly in rain, snow, or dust. It features shock resistance up to 6000J to withstand recoil and an IP68 waterproof rating for demanding outdoor missions.

Specifications for Guide TU435 3.0 400x300 35mm Thermal Scope:

Sensor:

• Type: Uncooled VOx Infrared Detector, 8 to 14µm
• Resolution: 400×300@12µm
• NETD: 20mK
• Frame rate: 50 Hz

Lens:

• Objective lens: 35mm, F1.0
• Field of view: 7.4°×4.4°
• FOV m@100m: 13×8
• Magnification: 4.4x~17.6x
• Detection range: 1800m/1950yd
• Focus: Manual

Display:

• Display type: 0.49'' AMOLED 1920×1080
• Color palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
• Eyepiece: Eye relief: 48mm; Diopter -5 to +5; Zoom: 14x

Hardware:

• WIFI: 2.4G, 5G
• Interface: USB-C (Charge/USB2.0)
• Tube diameter: Standard 30 mm
• Others: Microphone, Bluetooth

System:

• Recording function: Photo/Video (Audio recording included)
• Memory capacity: 128GB

Power:

• Battery type: 18500 ×1 Battery (Built-in) and 18650 ×1 Battery (External)
• Operating time: 12 hours

Environmental:

• Operating temp: -20°C to 50°C / -4°F to +122°F
• Shock: 6000J/1200G
• Encapsulation: IP68

Physical:

• Weight (g/oz): 738/26.03
• Size (mm/in): 374×89×76/14.72 ×3.50× 2.99
• Standard: Device, Lens Cover, Eye Mask, Quick-Release Scope Mount, Carry Bag, 18650 Battery ×2, Battery Charger, 5V 2A Adapter (US or UK or Australia or Europe), USB-A to USB-C Cable, Quick Start Guide, Warranty Card

TR Series is an economical civilian infrared thermal imaging scope that adopts high sensitivity thermal detector with three different lens options 25 mm, 35 mm, and 50 mm. The TR Series offers sharp, detailed images with 384 × 288 IR resolution while retaining accuracy. TR thermal scope also features a compact size, waterproof and dustproof, high shock resistance, rugged and durable, which performs impressively in harsh weather.

Features:

• 384x288 IR Resolution
• 35mm/F1.0 Focal Length
• 7.50°×5.64° Field of View
• 1024×768 Full-Colour AMOLED display
• Extended Picatinny Mount

Infrared detector/Sensor

• Detector type: Uncooled VOx Infrared
• Detector resolution and pitch: 348 × 288, 12 µm
• Spectral range: 8 to 14 µm
• NETD: =30 mk
• Frame rate: 50 Hz

Lens

• Focal length: 35 mm; F1.0
• Focus: Manual
• Field of View: 7.50° × 5.64°
• Optical zoom: 3.3x
• Digital zoom: 1x~4x

Display

• Display type: 0.39" OLED HD
• Resolution: 1024 x 768
• Eyepiece: Exit pupil distance=48mm; Diopter: +/- 4 to; Zoom: 14x
• Video output: Analog video

Power

• Battery type: Single Replaceable 18650 battery
• Battery life: = 8 hours

Interface

• USB: Type C
• Mechanical interface: Picatinny

Range Performance

• Detection range: 1400 m

Functions

• Scene modes: Enhanced, Highlight and Natural
• Colour palettes: White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot
• PIP: Available
• Hot spot tracking: Available
• Rough ranging: Available with APP
• WIFI: 2.4 G
• Supported Application: TargetIR
• Firmware OTA: Upgrade device firmware via app connection

Environmental

• Storage temperature range: -45°C to 70°C
• Operating temperature: -30°C to 50°C
• Humidity: 10 % to 95 % non-condensing
• Shock: 800 G at 1 ms half-sine pulse
• Drop: 1 m
• Encapsulation: IP67
• Certification: IP67, FCC, CE, RoHS, EAC, WEEE, UKCA, un38.3

Physical:

• Weight: = 540 g
• Dimensions: 208 × 88 × 66 mm

Included in box...

• Guide TR430
• Extended Picatinny Base
• Type C cable
• 5V 2A adapter
• 18650 battery
• Battery charger
• Lens cap
• Eye mask
• Quick start guide
• Warranty card
